1-fold rail-to-rail OP, 1.4 - 5.5 V, 13.5 KHz, 0.003 V/µs, SO-8

SGM8041, 710nA, Single Rail-to-Rail I/O Operational Amplifier

Description:
The SGM8041 is guaranteed to operate with a single- supply voltage as low as 1.4V, while drawing 710nA (TYP) of quiescent current. This device is also designed to support rail-to-rail input and output operation. This combination of features supports battery-powered and portable applications. The SGM8041 has a gain-bandwidth product of 14.5kHz (TYP) and is unity gain stable. These specifications make this operational amplifier appropriate for low frequency applications, such as battery current monitoring and sensor conditioning. The SGM8041 is offered in single configuration. The SGM8041 is available in Green SOT-23-5, SOIC-8 and MSOP-8 packages. It operates over an ambient temperature range of -40? to +85?.

Features:
- Low Quiescent Current: 710nA (TYP)
- Rail-to-Rail Input and Output
- Gain-Bandwidth Product: 14.5kHz at VS = 5V (TYP)
- Wide Supply Voltage Range: 1.4V to 5.5V
- Unity Gain Stable
- -40° to +85° Operating Temperature Range
- Available in Green SOT-23-5, SOIC-8 and MSOP-8 Packages

Applications:
- Toll Booth Tags
- Wearable Products
- Temperature Measurement
- Battery Powered Systems
