Dual-power op-amp
Housing: DIP-8
In stock
SKU TCA 0372 DP1
IC CIRCUIT
MPN TCA0372DP1
Manufacturer ONSEMI
€3.56
incl. 19% VAT · €2.99 excl. VAT
Package
DIP-8
Specifications
General
Type
Monolithic
Model
Operational amplifier
Mounting form
DIP-8
Other
Temperature range
-55..+150
Electrical values
Supply voltage
+40.0 VDC
Slew rate
1.4 V/µ sec
Output Current
1 A
Suppley Voltage Rejection
90 dB
Input Offset Voltage
1 mV
Input Offset Current
10 nA
Power Bandwidth
1400 kHz
Quiescent Current
5 mA
Input Bias Current
0.1 µA
Distortion
0.02 %
Manufacturer specifications
Manufacturer
ONSEMI
Manufacturer ID
TCA0372DP1
Weight
4.0E-4 kg
RoHS
conform
EAN/GTIN
9900000204839
HS-Code
85423310
