These microcontroller devices feature dual operational amplifiers and comparators making then an outstanding solution for signal conditioning and measurement applications.
- Baseline core architecture with 36 instructions
- Two hardware interrupts
- Four stack levels
- Flash program memory with self read/self write capability
- Internal 8 MHz oscillator
- Dual operational amplifier module with 3 MHz GBWP
- Dual analogue comparator module
- 8-channel 8-bit ADC
- Brown-out reset (BOR)
- On-board watchdog timer
- One 8-bit timer
- 25mA source/sink current I/O
- In-circuit serial programming (ICSP)
-Operating voltage: 2.0 - 5.5 V
- Low standby current: 100 [email protected] V, typical
In stock
SKU PIC 16F527-I/ML
MCU, PICmicro, 1.5 KB, 20 MHz, QFN-20
MPN PIC16F527-I/ML
Manufacturer MICROCHIP
€1.64
incl. 19% VAT · €1.38 excl. VAT
Package
QFN-20
Specifications
General
Type
PIC Controller
Technology
PIC® Flash
Model
PIC16F527
Design
WDT, ICSP, BOR, OpA
Mounting form
QFN-20
Specials
CPU clock
20 MHz
Implementation
Memory
1.5
RAM
0.068 kByte
EEPROM
64 Byte
I/O-Pins
18
8-bit Timer
1
PWM
0
Internal oscillator
4 MHz, 8 MHz
Analog comparator
2
Program Memory
1.5 KBytes
Interfaces
I²C
0
SPI
0
ODC
8
UART
0
I/O/USART
0
MSSP (SPI/I²C)
0
SSP (SPI/I²C)
0
Electrical values
Supply voltage
+2.0 ... +5.5 VDC
Other
Temperature range
-40 ... +85
Manufacturer specifications
Manufacturer
MICROCHIP
Manufacturer ID
PIC16F527-I/ML
Weight
0.001 kg
RoHS
conform
EAN/GTIN
9900001449413
HS-Code
85423190
