The Texas Instruments OPA828 operational amplifier with JFET input is a next-generation OPA627 and OPA827 operational amplifier (OPV) that combines high speed with high DC precision and AC performance. This op amp delivers low offset voltage, low drift over temperature, and is low noise with a noise floor of 60 nVRMS at 0.1 to 10 Hz. The OPA828 operates over a wide supply voltage range of ±4 V to ±18 V with a supply current of 5.5 mA/channel (typical).
With AC characteristics including a gain bandwidth product (GBW) of 45 MHz, a slew rate of 150 V/µs, and precision DC characteristics, the OPA828 is an excellent choice for use in a wide range of systems. These include high-speed, high-resolution data acquisition systems such as 16-bit to 18-bit mixed-signal systems. This also includes transimpedance amplifiers (I/V conversion), filters, ±10 V precision front ends, and high impedance sensor interface applications.
Key features
In stock
SKU OPA828ID
Operational amplifier, 1-fold, 45 MHz, 150 V/µs, ± 4 V ... ± 18
MPN OPA828ID
Manufacturer TEXAS INSTRUMENTS
€7.83
incl. 19% VAT · €6.58 excl. VAT
Package
SOIC-8
Specifications
General
Type
Operationsverstärker
Model
high speed
Mounting form
SOIC-8
Electrical values
Supply voltage
±18.0 VDC
Frequency range
45 MHz
Slew rate
150 V/µ sec
Input voltage
±18.0 VDC
Manufacturer specifications
Manufacturer
TEXAS INSTRUMENTS
Manufacturer ID
OPA828ID
Weight
0.001 kg
RoHS
conform
EAN/GTIN
9900003536098
HS-Code
85423310
